Chapter 4 - Setup
Manual Rev. 1.02 Page 29
Data-Link DL100 - Data Alarm Settings
A) Alarm 1 - [OFF]
B) Alarm 2 - [OFF]
C) Alarm 3 - [OFF]
...
O) Alarm 15 - [OFF]
P) Alarm 16 - [OFF]
Q) Setup Alarm Fields
R) Display Alarm Status
In the example above, alarms four through fourteen were cut out for brevity.
Data Alarm n Settings: Alarm n contains the settings for each individual alarm. Following is
an example of this menu.
Data-Link DL100 - Data Alarm 1
A) Alarm Enable [ON]
B) Alarm Name [Link Down]
C) Alarm Equation [errno="DN1"]
D) Threshold [3]
E) Auto-Clear when Threshold Reached [ON]
F) Alarm Counter Clear Interval [12 HOURS]
G) Alarm Counter Reset Time [00:00]
H) Actions [T1S]
I) Message []
J) Clear This Alarm Counter Now
… Alarm n: Alarm Enable toggles each individual data alarm monitor.
… Alarm n: Alarm Name sets the name for the alarm monitor. This name is reported with
SNMP trap actions.
… Alarm n: Alarm Equation defines the alarm equation using the alarm fields defined in the
previous menu.
… Alarm n: Threshold sets the number of times the alarm equation must be matched before an
alarm is triggered. If the alarm counter is allowed to grow beyond the threshold, the unit will not
trigger an alarm again until after the counter is reset.
… Alarm n: Auto-Clear when Threshold Reached controls whether the unit will clear the
alarm counter each time the threshold is met.
… Alarm n: Alarm Counter Clear Interval sets an interval at which the unit should clear the
match counter for an individual data alarm. Available options are: 2 hours, 4 hours, 6 hours, 8
hours, 12 hours, daily, and never. The first clear occurs at midnight.
… Alarm n: Alarm Counter Reset Time sets the time at which the daily clear should take place
if it is enabled in the Alarm Counter Clear Interval. This value is in 24-hour format.
… Alarm n: Actions contains the action string for the alarm.
