Omnitronix DL100 User’s Manual
Page 28
Data-Link DL100 - Dialback Security Menu
A) User 1 Phone Number []
B) User 2 Phone Number []
C) User 3 Phone Number []
D) User 4 Phone Number []
E) Dialback Security Enable [OFF]
Each of the phone numbers above corresponds with a one of the four user passwords from the
previous menu. If the password for user 2 is entered for a modem connection and a phone number
is entered in User 2 Phone Number, the DL100 will disconnect the inbound call and then call the
configured callback number. When making the callback, the unit will again require a valid user
password to gain access to the unit.
Dialback Security Enable toggles the dialback security functionality for all four users.
4.6 - Alarm Definitions
The alarm definitions branch contains all of the settings pertaining to data alarm monitoring,
percentage full, no data, and scheduled events.
Note: For an example-driven approach to defining alarm definitions, refer to Chapter 5.
Following is an example of this menu.
Data-Link DL100 - Alarm Definitions Menu
A) Data Alarm 1 Settings
B) Data Alarm 2 Settings
C) No-Data 1 Alarm Settings [OFF]
D) No-Data 2 Alarm Settings [OFF]
E) 80% Full Alarm Settings [OFF]
F) Scheduled Event 1 Settings [OFF]
G) Scheduled Event 2 Settings [OFF]
Data Alarm n Settings brings up the menu for data alarm configuration. The two data alarm
families are independent of one-another and should not be designed with any data referring
between the two. Following is an example of the menu.
