OMPHOBBY M4 MAX - 3-2 Tail Blade Set Installation

X Tail Control Rod Guide ( × 2)
Bearing
∅ 3x ∅ 6x2.5mm (× 4)
Ball Joint Screw - L3 (× 2)
X Tail Rotor Blade
Grip ( × 2)
Thrust Bearing
∅ 3x ∅ 6x2.8 (× 2)
3-2 Tail blade Set installation
Inner Dia. : Large
Inner Dia. : Small
Grease
(Already installed with retaining compound)
(Items are shipped pre-lubricated)
X Tail Fin (× 1)X Tail Boom Mounting Brace ( × 1)
M4X-301
X Tail Pulley Set ( × 1) X Tail Rotor Shaft ( × 1)
Screw M2x10.5mm ( × 1)
Flanged Bearing
∅ 5x ∅ 13x4mm (× 2)
Tail Belt 1280mm ( × 1)
Shim
∅ 3x ∅ 4.5x0.2mm ( × 2 )
12
WWW.OMPHOBBY.COM
Installation steps 安装步骤
Socket cap screw
M2.5x5mm ( × 6)
X Tail Control Rod Guide ( × 2)
about 140mm about 180mm
X tail pipe short washer ( × 1)
X tail boom long washer ( × 1) X Carbon Tube Liner (× 1)
Shim
∅ 2.6x ∅ 5x0.7mm ( × 1 )
