7. Connection Procedure
7.3.3. Transferring Project Data
Transfer the project data from the Sysmac Studio to the Controller.
1
Select Online from the
Controller Menu.
2
When an online connection is
established, a yellow bar is
displayed on the top of the Edit
Pane.
3
Select Synchronization from
the Controller Menu.
4
The Synchronization Dialog Box
is displayed.
Check that the data to transfer
(NJ501 in the right figure) is
selected. Then, click the
Transfer to Controller Button.
