Conductive Level Controller 61F-GP-N8 E-11
Level
Controllers
BS-1
Electrode Separators
F03-14 1P (for Single Pole) F03-14 3P (for Three Poles)
Connecting Sockets
Track Mounted Socket
Back Connecting Socket
12 39
5150
101
M18
P = 1.5
24 dia.
Width across flats: 20
Nut (iron)
Terminal bolt
SUS304 (M4) P=0.7
Two M4
P = 0.7
M18 P=1.5
(fine screw thread)
6.5 dia.
28 dia.
20
41 dia.
Three, 7 dia.
7
±
0.2
PF083A-E
Mounting Holes
Two, M4 or 4.5-dia. holes
52 max.
41 max.
21 max.
25 dia.
Eight, M3.5 x 7
sems screws
Two, 4.2-dia.
holes
Terminal Arrangement/
Internal Connections
(Top View)
50.5 max.
35 max.
30 dia.
Two, 2-dia. holes
Approx. 20.5
PL08
Mounting HolesTerminal arrangement/
Internal Connections
(Bottom View)
Two, 3.5-dia. or
M3 Controller
mounting holes
Two, 3.5-dia. or M3
socket mounting holes
31-dia.
hole
