5-5 Expansion Instructions
The C200HX/HG/HE PCs have more instructions that require function codes
(121) than function codes (100), so some instructions do not have fixed function
codes. These instructions, called expansion instructions, are listed in the follow-
ing table. Default function codes are given for the instructions that have them.
An expansion instruction can be assigned one of 18 function codes using the
Programming Console’s Expansion Instruction Function Code Assignments op-
eration. The 18 function codes are: 17, 18, 19, 47, 48, 60 to 69, 87, 88, and 89.
Refer to 7-2-14 Expansion Instruction Function Code Assignments for details on
assigning function codes.
Code Mnemonic Name Page
17 (@)ASFT ASYNCHRONOUS SHIFT REGISTER 178
18 (@)SCAN CYCLE TIME 305
19 (@)MCMP MULTI-WORD COMPARE 192
47 (@)LMSG 32-CHARACTER MESSAGE 308
48 (@)TERM TERMINAL MODE 309
60 CMPL DOUBLE COMPARE 196
61 (@)MPRF GROUP-2 HIGH-DENSITY I/O REFRESH 311
62 (@)XFRB TRANSFER BITS 189
63 (@)LINE COLUMN TO LINE 224
64 (@)COLM LINE TO COLUMN 225
65 (@)SEC HOURS TO SECONDS 207
66 (@)HMS SECONDS TO HOURS 208
67 (@)BCNT BIT COUNTER 312
68 (@)BCMP BLOCK COMPARE 197
69 (@)APR ARITHMETIC PROCESS 263
87 TTIM TOTALIZING TIMER 165
88 ZCP AREA RANGE COMPARE 200
89 (@)INT INTERRUPT CONTROL 289
--- 7SEG 7-SEGMENT DISPLAY OUTPUT 340
--- (@)ADBL DOUBLE BINARY ADD 249
--- AVG AVERAGE VALUE 259
--- (@)BXF2 EM BANK TRANSFER 191
--- CPS SIGNED BINARY COMPARE 202
--- CPSL DOUBLE SIGNED BINARY COMPARE 203
--- CMCR PCMCIA CARD MACRO 357
--- (@)DBS SIGNED BINARY DIVIDE 255
--- (@)DBSL DOUBLE SIGNED BINARY DIVIDE 256
--- DSW DIGITAL SWITCH INPUT 343
--- @EMBC SELECT EM BANK 321
--- (@)FCS FCS CALCULATE 312
--- FPD FAILURE POINT DETECT 314
--- (@)HEX ASCII-TO-HEXADECIMAL 219
--- HKY HEXADECIMAL KEY INPUT 347
--- (@)IEMS INDIRECT EM ADDRESSING 320
--- (@)IORD SPECIAL I/O UNIT READ 354
--- (@)IOWR SPECIAL I/O UNIT WRITE 355
--- (@)MAX FIND MAXIMUM 257
--- (@)MBS SIGNED BINARY MULTIPLY 253
--- (@)MBSL DOUBLE SIGNED BINARY MULTIPLY 254
Expansion Instructions Section 5-5
