Precautions DVB(53) cannot be used to divide signed binary data. Use DBS(––) instead. Re-
fer to 5-20-9 SIGNED BINARY DIVIDE – DBS(––) for details.
Flags ER: Dr contains 0.
Indirectly addressed DM word is non-existent. (Content of DM word is
not BCD, or the DM area boundary has been exceeded.)
EQ: ON when the result is 0.
N: ON when bit 15 of R is set to 1.
Example
DVB(53)
001
LR 20
HR 05
Address Instruction Operands
00000 LD 00000
00001 DVB(53)
001
LR 0020
HR 05
00000
Dd: IR 001
10F7
Dr: LR 20
0003
R: HR 05
05A7
R+1: HR 06
0002

Remainder (2) Quotient (1447)
5-20-5 DOUBLE BINARY ADD – ADBL(––)
Au: First augend word (binary)
IR, SR, AR, DM, HR, LR
Ad: First addend word (binary)
IR, SR, AR, DM, HR, LR
Ladder Symbols
Operand Data Areas
R: First result word
IR, SR, AR, DM, HR, LR
ADBL(––)
Au
Ad
R
@ADBL(––)
Au
Ad
R
Limitations Au and Au+1 must be in the same data area, as must Ad and Ad+1, and R and
R+1.
Description When the execution condition is OFF, ADBL(––) is not executed. When the
execution condition is ON, ADBL(––)) adds the eight-digit contents of Au+1 and
Au, the eight-digit contents of Ad+1 and Ad, and CY, and places the result in R
and R+1. CY will be set if the result is greater than FFFF FFFF.
Au + 1 Au
Ad + 1 Ad
R + 1 R
+
CY
CY
Binary Calculations Section 5-20
