Omron C200HX - Page 164

Instruction Set Lists Section 5-7
146
Mnemonic PageNameWordsCode
ASFT(@) 17 4 ASYNCHRONOUS SHIFT REGISTER 178
ASL (@) 25 2 ARITHMETIC SHIFT LEFT 175
ASR (@) 26 2 ARITHMETIC SHIFT RIGHT 175
AVG (@) –– 4 AVERAGE VALUE 259
BCD (@) 24 3 BINARY TO BCD 205
BCDL (@) 59 3 DOUBLE BINARY-TO-DOUBLE BCD 206
BCMP (@) 68 4 BLOCK COMPARE 197
BCNT (@) 67 4 BIT COUNTER 312
BIN (@) 23 3 BCD-TO-BINARY 204
BINL (@) 58 3 DOUBLE BCD-TO-DOUBLE BINARY 205
BSET (@) 71 4 BLOCK SET 181
BXF2 (@) –– 4 EM BLOCK TRANSFER 190
CLC (@) 41 1 CLEAR CARRY 229
CMCR (@) –– 4 PCMCIA CARD MACRO 357
CMP 20 3 COMPARE 193
CMPL 60 4 DOUBLE COMPARE 196
CNT None 2 COUNTER 166
CNTR 12 3 REVERSIBLE COUNTER 169
COLL (@) 81 4 DATA COLLECT 185
COLM(@) 64 4 LINE TO COLUMN 225
COM (@) 29 2 COMPLEMENT 277
CPS –– 4 SIGNED BINARY COMPARE 202
CPSL –– 4 DOUBLE SIGNED BINARY COMPARE 203
DBS (@) –– 4 SIGNED BINARY DIVIDE 255
DBSL (@) –– 4 DOUBLE SIGNED BINARY DIVIDE 256
DEC (@) 39 2 BCD DECREMENT 228
DIFD 14 2 DIFFERENTIATE DOWN 151
DIFU 13 2 DIFFERENTIATE UP 151
DIST (@) 80 4 SINGLE WORD DISTRIBUTE 183
DIV (@) 33 4 BCD DIVIDE 236
DIVL (@) 57 4 DOUBLE BCD DIVIDE 237
DMPX (@) 77 4 16-TO-4/256-TO-8 ENCODER 212
DSW –– 4 DIGITAL SWITCH 343
DVB (@) 53 4 BINARY DIVIDE 248
EMBC (@) –– 2 SELECT EM BANK 321
END 01 1 END 158
FAL (@) 06 2 FAILURE ALARM AND RESET 304
FALS 07 2 SEVERE FAILURE ALARM 304
FCS (@) –– 4 FCS CALCULATE 312
FDIV (@) 79 4 FLOATING POINT DIVIDE 238
FPD –– 4 FAILURE POINT DETECT 314
HEX (@) –– 4 ASCII-TO-HEXADECIMAL 219
HKY –– 4 HEXADECIMAL KEY INPUT 347
HMS (@) 66 4 SECONDS TO HOURS 208
IEMS (@) –– 2 INDIRECT EM ADDRESSING 320
IL 02 1 INTERLOCK 155
ILC 03 1 INTERLOCK CLEAR 155
INC (@) 38 2 INCREMENT 228
INT (@) 89 4 INTERRUPT CONTROL 289
