303
STEP(08) LR 0000
SNXT(09) LR 0001
STEP(08) LR 0001
STEP(08) LR 0004
SNXT(09) LR 0005
STEP(08)
Process A
Process B
Process C
00002 (SW3)
00005 (SW7)
Process A started.
Process A reset.
Process B started.
Process E reset.
00001 (SW1 and SW2))
SNXT(09) LR 0000
SNXT(09) LR 0002
Process C started.
LR 0003
SNXT(09) LR 0004
00004 (SW5 and SW6)
LR 0003
STEP(08) LR 0002
Process E started.
Used to
turn off
process D.
00003 (SW4)
SNXT(09) LR 0003
STEP(08) LR 0003
Process C reset.
Process D started.
Process D
Process E
