376
Instruction OFF execution time (μs)ON execution time (μs)ConditionsInstruction
C200HEC200HGC200HXC200HEC200HGC200HX
Conditions
LMSG(––) Word for SV 17.95 32.65 0.313 0.469 0.938
Default: (47) DM for SV 27.65 42.35
TERM(––)
Default: (48)
--- 8.55 23.25 0.313 0.469 0.938
CMPL(––) When comparing words to words 16.55 31.25 0.313 0.469 0.938
Default: (60) When comparing DM to DM 38.5 53.2
MPRF(––) 1 Unit 2.00 16.7 0.313 0.469 0.938
Default: (61) 10 Units 13.00 27.7
XFRB(––) Sending 1 bit from word to word 22.45 37.15 0.313 0.469 0.938
Default: (62) Sending FF bits from DM to DM 142.6 157.3
LINE(––)
Default: (63)
When transferring from words to a
constant
59.7 74.4 0.313 0.469 0.938
e au (63)
When transferring from words to a word 62.1 76.8
When transferring DM to DM 182.5 197.2
COLM(––)
Default: (64)
When transferring from a constant to
words
72.7 87.4 0.313 0.469 0.938
eau (6 )
When transferring from a word to words 74.9 89.6
When transferring DM to DM 190.5 205.2
SEC(––) DM to DM 35.35 50.05 0.313 0.469 0.938
Default: (65) DM to DM 56.3 71
HMS(––)
DM to DM 36.5 51.2 0.313 0.469 0.938
()
Default: (66)
DM to DM 57.7 72.4
BCNT(––)
Constant for SV 39.1 53.8 0.313 0.469 0.938
()
Default: (67)
DM for SV 26.5 ms (see
note 2)
BCMP(––)
Default: (68)
Comparing constant to word-designated
table
62.1 76.8 0.313 0.469 0.938
e au (68)
To a word after comparing with a word 63.1 77.8
Comparing DM → DM-designated
table
98.2 112.9
APR(––)
SIN designation 24.25 38.95 0.313 0.469 0.938
()
Default: (69)
DM for SV 473 487.7
TTIM(––)
Default: (87)
Setting to a constant 27.55 42.25 Constant
input
OFF:
23.15
R: 24.15
IL: 20.55
JPM:
19.55
Setting to DM 35.5 50.2 Constant
input
OFF:
35.30
R: 36.3
IL: 32.7
JPM:
31.9
ZCP(––)
D f l (88)
Comparing a constant to a word 16.75 31.45 0.313 0.469 0.938
()
Default: (88)
Comparing a word to a word 17.65 32.35
Comparing DM to a DM 49.7 64.4
INT(––)
Default: (89)
Word for SV 19.90 to 198.50 (see
note 3)
0.313 0.469 0.938
Default: (89)
DM for SV 19.90 to 213.5 (see
note 3)
TKY(––) Input to DM 25.65 40.35 0.313 0.469 0.938
Input to DM 46.7 61.4
RXD(––) When designating a word 31.5 30.4 0.313 0.469 0.938
When designating DM 73.5 72.4
Instruction Execution Times Section 6-3
