Multiple Address Monitoring
00000
00000
TIM 000
T000
0100
00000 T000
0100
00001 T000
0100
00001 T000
OFF 0100
D000000001 T000
^OFF 0100
D000000001 T000
10FF^ OFF 0100
T000D000000001
0100 10FF^ OFF
D000000001
10FF^ OFF
00001
^ OFF
00000
CONT 00001
00000
CHANNEL DM 0000
0000000001
S ONR OFF
Indicates Force Reset
in operation.
Indicates Force Set
in operation.
Cancels monitoring
of leftmost address
Monitor operation
is cancelled
7-2-2 Forced Set/Reset
When the Bit/Digit Monitor operation is being performed and a bit, timer, or
counter address is leftmost on the display, PLAY/SET can be pressed to turn ON
the bit, start the timer, or increment the counter and REC/RESET can be pressed
to turn OFF the bit or reset the timer or counter. Timers will not operate in PRO-
GRAM mode. SR bits cannot be turned ON and OFF with this operation.
Programming Console Operations Section 7-2
