Appendix CError and Arithmetic Flag Operation
528
Mnemonic Page25402
(N)
25405
(UF)
25404
(OF)
25507
(LE)
25506
(EQ)
25505
(GR)
25504
(CY)
25503
(ER)
CLC(41) --- --- --- --- --- --- --- --- 229
MSG(46) µ --- --- --- --- --- --- --- 307
ADB(50) µ µ --- µ --- µ µ µ 243
SBB(51) µ µ --- µ --- µ µ µ 245
MLB(52) µ --- --- µ --- --- --- µ 248
DVB(53) µ --- --- µ --- --- --- µ 248
ADDL(54) µ µ --- µ --- --- --- --- 230
SUBL(55) µ µ --- µ --- --- --- --- 233
MULL(56) µ --- --- µ --- --- --- --- 236
DIVL(57) µ --- --- µ --- --- --- --- 237
BINL(58) µ --- --- µ --- --- --- OFF 205
BCDL(59) µ --- --- µ --- --- --- --- 206
XFER(70) µ --- --- --- --- --- --- --- 182
BSET(71) µ --- --- --- --- --- --- --- 181
ROOT(72) µ --- --- µ --- --- --- --- 241
XCHG(73) µ --- --- --- --- --- --- --- 183
SLD(74) µ --- --- --- --- --- --- --- 177
SRD(75) µ --- --- --- --- --- --- --- 177
MLPX(76) µ --- --- --- --- --- --- --- 209
DMPX(77) µ --- --- --- --- --- --- --- 212
SDEC(78) µ --- --- --- --- --- --- --- 215
FDIV(79) µ --- --- --- µ --- --- --- 238
DIST(80) µ --- --- --- µ --- --- µ 183
COLL(81) µ --- --- --- µ --- --- µ 185
MOVB(82) µ --- --- --- --- --- --- --- 187
MOVD(83) µ --- --- --- --- --- --- --- 188
SFTR(84) µ µ --- --- --- --- --- --- 173
TCMP(85) µ --- --- µ --- --- --- --- 199
ASC(86) µ --- --- --- --- --- --- --- 218
SEND(90) µ --- --- --- --- --- --- --- 322
SBS(91) µ --- --- --- --- --- --- --- 285
SBN(92) µ µ µ µ µ µ µ µ 286
WDT(94) µ --- --- --- --- --- --- --- 310
IORF(97) µ --- --- --- --- --- --- --- 310
RECV(98) µ --- --- --- --- --- --- --- 327
MCRO(99) µ --- --- --- --- --- --- --- 287
Expansion Instructions
The default function codes are shown for the instructions that have default function codes.
Mnemonic 25503
(ER)
25504
(CY)
25505
(GR)
25506
(EQ)
25507
(LE)
25404
(OF)
25405
(UF)
25402
(N)
Page
7SEG(––) µ --- --- --- --- --- --- --- 340
ADBL(––) µ µ --- µ --- µ µ µ 249
APR(69) µ --- --- µ --- --- --- µ 263
ASFT(17) µ --- --- --- --- --- --- --- 178
AVG(––) µ --- --- --- --- --- --- --- 259
BCMP(68) µ --- --- --- --- --- --- --- 197
BCNT(67) µ --- --- µ --- --- --- --- 312
