FINS Commands Addressed to EtherNet/IP Units or Built-in EtherNet/IP Ports Appendix E
Mode Setting (Response)
The mode setting in the system setup is returned.
Broadcast Address Setting
Communications Partner IP Address Conversion Method Setting
FINS/UDP Port Number Setting
FINS/TCP Port Number Setting
Baud Rate Setting
SNTP Server Specification Method
Ethernet Address (Response)
The Ethernet address of the EtherNet/IP Unit or built-in EtherNet/IP port is returned.
Note This Ethernet address is listed on the label on the side of the EtherNet/IP Unit or (for a built-in EtherNet/
IP port), on the CPU Unit.
Bit 1: Broadcast setting
Bit 4: UDP port number setting for FINS
Bits 2 and 3: IP address conversion method
0 1 2 3 4 5 67 89 10 11 12 1314 15
Bit 5: TCP port number setting for FINS/TCP
Bit 8: Transmission speed (baud rate)
Bit 9: SNTP server s
ecification method
Bit 1 Meaning
0 Broadcast with host number set to all ones (4.3BSD specifications)
1 Broadcast with host number set to all zeroes (4.2BSD specifications)
Bit 3 Bit 2 Meaning
0 0 Automatic generation method (dynamic)
0 1 Automatic generation method (static)
1 0 IP address table reference method
1 1 Combined method (IP address table reference + automatic generation
(dynamic))
Bit 4 Meaning
0 Default (9600)
1 Unit Setup value
Bit 5 Meaning
0 Default (9600)
1 Unit Setup value
Bit 8 Meaning
0 Automatic detection
1Fixed
Bit 9 Meaning
0 IP address
1Host name
