FINS Commands Addressed to EtherNet/IP Units or Built-in EtherNet/IP Ports Appendix E
Response Codes
CONTROLLER STATUS READ
Reads the controller status.
Command Block
Response Block
Parameters
Communications Status 3 (Response)
Ethernet Basic Setting Error
IP Address Table Error
Response code Description
0000 Normal end
1001 Command too large
06 01
Command cod
e
06 01 4 byte 4 byte
Total number
of
p
ackets sent
4 byte
Total number
of
send errors
4 byte
Total number
of
send collisions
4 byte
Response
code
Command
code
2 byte
Total number
of
p
ackets received
Total number
of
receive errors
Communications
status 3
Bit 3: IP address table error
0123 4 5 6 78910 11 12 13 1415
Bit 4: IP router table error
Bit 6: Routing table error
Bit 15: Non-volatile memory error
Bit 14: Address mismatch
Bit 2: EtherNet/IP basic setting error
Bit 9: EtherNet/IP advanced setting erro
r
Bit 10: BOOTP server error
Bit 11: SNTP server error
Bit 5: DNS server error
Bit 2 Meaning
0 No error
1 An error (such as an invalid IP address) was detected during the validity check of parameters related to the
TCP/IP Interface Object and Ether Link Object.
Bit 3 Meaning
0 No error
1 Error detected (More than 32 records, invalid IP address, or invalid FINS node address).
