Mounting Dimensions
43.4 88
170.9
119
125
14.9
28.6
119
125
4-M4
PAN HEAD SCREW
2-M4
PAN HEAD SCREW
Front mounting Sideways mounting
Appendices
A-3
CK3E-series Programmable Multi-Axis Controller User’s Manual Hardware (I610)
