[Slot1(NX-SL3500)Output Data
Set1]
Registering Node1/Unit3
(NX-SOD400)
Click New in the Variables tab
page, and register 4 variables
shown on the right.
FSoE Master CMD
#x7040:01
USINT
Safety Output 1st Byte
#x7041:01
USINT
Group: Module 1(NX-SL3500).Output Data Set 1
Datatype : USINT
Count : 2
FSoE Master CRC_0
#x7040:03
UINT
FSoE Master Conn_ID
#x7040:02
UINT
Group: Module 1(NX-SL3500).Output Data Set 1
Datatype : UINT
Count : 2
