Omron E2C - Engineering Data; Typical Operating Range Charts

E2C
E2C
9
Engineering Data
Operating Range (Typical)
E2C-CR5B
E2C-CR8
j
E2C-X1A/E2C-C1A
Sensing object: Iron
5x5x1mm
Sensing distance
(variable): 0.2 to 0.5 mm
Sensing distance X (mm)
2-dia. Sensing Head
Sensing object: Iron
5x5x1mm
Sensing distance
(variable): 0.16 to 0.8 mm
E2C-CR8
j
Sensing Head
Sensing object: Iron
5x5x1mm
Sensing distance
(variable): 0.2 to 1 mm
E2C-X1A Sensing Head
E2C-C1A Sensing Head
Sensing distance X (mm)
Sensing distance X (mm)
Y (mm) Y (mm)
Y (mm)
E2EC-X1R5A E2EC-X2A E2EC-X5A
Sensing distance X (mm)
Sensing distance X (mm)
Sensing distance X (mm)
Sensing object: Iron
8x8x1mm
Sensing distance
(variable): 0.3 to 1.5 mm
E2C-X1R5A Sensing Head
Sensing object: Iron
12 x 12 x 1 mm
Sensing distance
(variable): 0.4 to 2 mm
E2C-X2A Sensing Head
Sensing object: Iron
18x18x1mm
Sensing distance
(variable): 1 to 5 mm
E2C-X5A Sensing Head
Y (mm)
Y (mm) Y (mm)
E2EC-CX10A E2EC-C20MA
Sensing distance X (mm)
Sensing distance X (mm)
E2C-X10A Sensing Head
E2C-X20MA Sensing Head
Sensing object: Iron
30x30x1mm
Sensing distance
(variable): 2 to10 mm
Sensing object: Iron
50x50x1mm
Sensing distance
(variable): 4 to 20 mm
Y (mm) Y (mm)
