Omron E3AS-HL500MT 2M User Manual

Near-sidethresholdvalue
Far-sidethresholdvalue
Margin
Background(referencesurface)
OFF
ON
ON
Margin
Teaching
4
・Foroutput1(Pin4,blackwire),5typesofteachingareusablebybutton
operations.
・Foroutput2(Pin2,whitewire),teachingisnotusablebybuttonoperations.
However,output2teachingcanbeexecutedbythecommunication
commandsofIO-Link(only2-pointteachingandbackgroundteachingis
usable).
■Teachingoperationlookuptable
TEACH
T
TEACH
T
Item
2-pointteaching
PressQuickly
PressQuickly
PressQuickly
TEACH
T
TEACH
T
Operation
TEACH
T
Item
*1.Thisisthefactorysetting.
Whenpressingquickly,itmustlongerthan25msandshorterthan1s.
Whenpressingandholding,itmustshorterthan5s.
TeachingSelection[Teach3sec]
[Background]*1
[Object]
Backgroundteaching
Objectteaching
Press&Hold
Press&Hold
Operation
Item
Bg.Ref.TeachingSelection
[Ref.Teach]
[Normal]*1
[Sensitive]
Bg.referenceteaching(normal)
Bg.referenceteaching(sensitive)
Operation
■2-pointTeaching
BasicTeaching
4-1
Thisisthebasicsetting.
1. Pressthebuttonquicklywithoutanyobjects(longerthan25msandshorterthan1s).
・Thethresholdvalueissetatadistancebetweenbackgroundandobject.
・Maximumdetectiondistanceisset(thresholdvalueissetwithHL150□:150
mm,HL500□:500mmasateachingpoint)whenteachingisperformedwith
eitherthefirstorsecondpointwithoutdetectedobjectorbackground.
・ShownaboveisapplicabletothecaseofN.O.outputlogic.InthecaseofN.C.,
thisisinverted.
TEACH
T
2. Pressthebuttonquicklywithanobject(longerthan25msandshorterthan1s).
TEACH
T
BGS
OFF
ON
・[Single]isselectedautomaticallyastheoutputmode.
・Settingisnoproblemevenifuseroperationswithanobjectandwithoutany
objectsareperformedinversely.
●Thresholdsettingafterteachingiscompleted
Thresholdvalue
Background
Thresholdvalue
Background(referencesurface)
Object
・Thiscanbeexecutedifsetting[Background]whenexecutingTeaching
Selectionin"6DetailedSettings"( page9)
([Background]isthefactorysetting.)
・Thisissuitablefordetectionofanobjectfromwhichsmallamountoflightisreturnedto
thereceivingsurface(suchasmirror,uneven,andlowreflectance).
・ Thisteachingcanbeexecutedifsetting[Normal]whenexecutingBackgroundReference
TeachingSelectionin"6DetailedSettings"(page9)([Normal]isthefactorysetting.)
■BackgroundTeaching[Teach3sec(Background)]
■
BackgroundReferenceTeaching(Normal)[Ref.Tech(Normal)]
Usetodetectanobjectcloserthanthebackground.
Usetodetectsomethingshapedcomplicatedly.
Alternate
lighting
Alternate
lighting
●Thresholdsettingafterteachingiscompleted
1. Pressandholdthebuttonwithoutanyobjects(longerthan1sandshorterthan5s).
Releasethebuttonwhen[BackgroundTeach]isdisplayedonthedisplay
TEACH
T
BGS
・[Single]isselectedautomaticallyastheoutputmode.
2. Pressandholdthebuttonwithoutanyobjects(longerthan1sandshorterthan5s). 
Releasethebuttonwhen[Reference(Normal)]isdisplayedonthedisplay
TEACH
T
・[WindowFGS]isselectedautomaticallyastheoutputmode.
1.Pressthebuttonquicklywithoutanyobjects(longerthan25msandshorterthan1s).
TEACH
T
(FGS)
Margin
OFF
ON
・Thethresholdvalueissetonthenearsidetothebackground.
・Ifteachingisexecutedwithoutanybackgrounds,themaximumdetecting
distance(HL150□:150mm,HL500□:500mm)willbesetasthethreshold
value.
・Marginissetautomaticallytotheoptimalvalueaccordingtothedetecting
distance.
・ShownaboveisapplicabletothecaseofN.O.outputlogic.InthecaseofN.C.,
thisisinverted.
●Thresholdsettingafterteachingiscompleted
・Thethresholdvalueissetwith±margintothebackground.
・Marginissetautomaticallytotheoptimalvalueaccordingtothedetecting
distance.
・ShownaboveisapplicabletothecaseofN.O.outputlogic.InthecaseofN.C.,
thisisinverted.
5
