MainScreen
ResponseTime
6-1(page10)
3sec
DetailedSettings
6
UP
UP
DOWN
DOWN
UP
DOWN
Response
50ms
TEACH
T
50ms 10ms 1.5ms
[UP]Leftshift/Numericalvalue+
[DOWN]Rightshift/Numericalvalue-
Output1Mode
3-4(page4)
UP
DOWN
Out1Mode
Single
TEACH
T
Single WindowBGS WindowFGS Dist+Int*1
Displayedonlywhentheoutput2function=Out2Single
Displayedonlywhentheoutput2function=Input
Output1
TimerMode
6-3(page10)
UP
DOWN
TimerMode1
Off
TEACH
T
Off OnDelay OffDelay OneShot
DisplaySelection
6-4(page10)
UP
DOWN
Display
Standard
TEACH
T
Standard Simple Bar ON/OFF
Output2
TimerMode
6-3(page10)
UP
DOWN
TimerMode2
Off
TEACH
T
Off OnDelay OffDelay OneShot
Output2
Function
3-2(page3)
UP
DOWN
Out2Func.
Out1Invert
TEACH
T
Out1Invert Out2Single*3 Input Error
ExternalInput
3-3(page3)
UP
DOWN
InputFunc.
LaserOff
TEACH
T
LaserOff Teach ZeroReset
Output1Logic
6-2(page10)
UP
DOWN
Out1Logic
N.O.
TEACH
T
N.O. N.C.
AdvancedSettings
N
Y
Advanced
Settings=ON
Advanced
Settings=OFF
AdvancedSettings=ON
UP
DOWN
DOWN
Adv.Setting
Off
TEACH
T
Off On
Initialization
 5-2(page7)
DOWN
Initialize?
No
TEACH
T
No Yes
Output2Logic
6-2(page10)
UP
DOWN
Out2Logic
N.O.
TEACH
T
N.O. N.C.
Output1
TimerTime*2
UP
DOWN
TimerTime1
5
TEACH
T
1〜9999
Output2
TimerTime*4
UP
DOWN
TimerTime2
5
TEACH
T
1〜9999
*2.Displayedonlywhenoutput1timermode≠OFF
*4.Displayedonlywhenoutput2timermode≠OFF.
Unit:ms(reference)
Unit:ms(reference)
Thischartshowsthetransitionofthemenusettingscreen.
Ifanswering[Yes]to[Initialize?]andtransitingtoitemsetting,initializationis
executedandthescreenmovesbacktothemainscreen.
*1.Displayedonlywhenbackgroundreferenceteaching(sensitive)isexecuted
(output1mode=Dist+Int).
8
*3.Notdisplayedonlywhenbackgroundreferenceteaching(sensitive)isexecuted
(output1mode=Dist+Int).
