A Appendices
A - 46
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
• This object reads the blue detection level (incident light level) of the Sensor Amplifier with the unit
number specified by the index.
• This object reads the pattern of the detection level (incident light level) of the Sensor with the unit
number specified by the index.
* The reading cycle and data are as follows.
The light levels read in the initial 2 bits of the 1st and 2nd bytes and the 3rd and 4th bytes are
distinguished.
4062 + (N-1) × 80
hex
No_01 ... 30 Color Detection Level (BLUE)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Color Detection Level (BLUE)
Range: 0 to 9999
(0000 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
4063 + (N-1) × 80
hex
No_01 ... 30 Change Response Data pattern
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Change Response Data pattern
Range: 01 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RW PDO map: Not possible
Data
Setting
CA0 AA□0 / VA□0
0000 hex Reads the amount of detection level (incident
light level) at the Sensor Amplifier in 1 ms.
Reads the input measurement value. (Before
scaling & zero reset)
0001 hex Reads the amount of detection level (incident
light level) at the Sensor Amplifier and the
amount of RGB incident light at a cycle of 1 ms.*
Reads the displayed measurement value. (After
scaling & zero reset)
byte 3rd byte, 4th byte 1st byte, 2nd byte
bit 31 30 29 to 16 15 14 13 to 0
1st cycle 0 1 Received red light level 0 0 Sensor detection level
(received level)
2nd cycle 1 1 Received blue light level 1 0 Received green light level
3rd cycle Same as 1st cycle
4th cycle Same as 2nd cycle
::
To Next Page
