A Appendices
A - 48
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
• If you want to set tuning information to a different amplifier, use this index.
• Set the Power Tuning Level of the unit number specified by the index.
• Adjust the maximum incident light level of R, G, B during execution of smart tuning to the power
tuning level.
• This object sets the direction of the Sensor with the unit number that is specified by the index.
* Items with asterisks are supported from E3NW-ECT version 1.03.
You can check the version with object index 100A hex. (Refer to "A-1-4 Communication Objects" on page A-4.)
4068 + (N-1) × 80
hex
No_01 ... 30 Tuning Setting (5)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning Setting (5)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 4 bytes (U32) Access: RW PDO map: Not possible
4069 + (N-1) × 80
hex
No_01 ... 30 Light projection power (CA0)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Light projection power (CA0)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
4071 + (N-1) × 80
hex
No_01 ... 30 Direction*
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Direction
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Data Setting
0000 hex Normal
0001 hex Reversed
