Omron E3S User Manual

E3S
13
Accessories (Order Separately)
5
25
5
4.2
10.2
20.2
25.4
5.6
41
2.1R
4.2
25.4
92.1
82.1
9 29.1
25.4
Two, M4 slotted
hexagonal bolts
Two, M4
Mounting Holes
Applicable models:
E3S-5E41
E3S-R2E41
E3S-DS30E41
Special Mounting Bracket
E39-L2
3.2
15.70
4
5
20
33
4
20
3.2
68.5
60.8
20
28.5
4
Two, M3
Mounting Holes
Applicable models:
E3S-2E41
E3S-DS10E41
20
Two, M3
E39-L4
34
40.3
5259.9
2.7
8
1.6
7.5
7
Two, 3.5 dia.
Material:
Reflective surface: Acrylic
Rear surface: ABS
Reflector
E39-R1
(Provided with the E3S-R2E4(41) Retro-reflective Reflector.)
4
13 dia.
9.3 dia.
Applicable models:
Provided with the E3S-5E4(41), E3S-DS30E4(41), E3S-R2E4(41).
Note: Cannot be used for the E3S-DS10E4 (41).
Sensitivity Adjuster (Provided)
E39-G1

Omron E3S Specifications

General

Output Type	NPN or PNP
Response Time	1 ms max
Light Source	Infrared LED
Protection Circuit	Reverse polarity protection
Output Current	100 mA max.
Operating Temperature	-25 to 55 °C
Storage Temperature	-40 to 70 °C
Housing Material	ABS
Connection	connector
