5 Advanced Operations
5 - 56
E5@C Digital Temperature Controllers User’s Manual (H174)
 Monitor/Setting Item
*1 With the E5CC, E5CC-U, E5CC-B, E5DC, E5DC-B, or E5GC, only the PV and SP can be displayed.
*2 The Alarm Value 1 parameter is displayed even if the Alarm 1 Type parameter is set for no alarm.
However, any value that is set is not valid.
Monitor/Setting Item 1
(Advanced Function Setting
Level)
Setting the PF Setting parameter to the Monitor/Setting Item makes it
possible to display monitor/setting items using the S Key. The following table
shows the details of the settings. For setting (monitor) ranges, refer to the
applicable parameter.
Set value Setting
Remarks
Monitor/Setting Display
0 Disabled ---
1 PV/SP/Multi-SP
Can be set. (SP)
*1
---
2 PV/SP/MV (valve opening for Position-pro-
portional Model)
Can be set. (SP)
*1
---
3 PV/SP /Soak time remain
Can be set. (SP)
*1
---
4 Proportional band (P) Can be set. p
5 Integral time (I) Can be set. i
6 Derivative time (D) Can be set. d
7 Alarm value 1 Can be set. al-1
8 Alarm value upper limit 1 Can be set. al1h
9 Alarm value lower limit 1 Can be set. al1l
10 Alarm value 2 Can be set. al-2
11 Alarm value upper limit 2 Can be set. al2h
12 Alarm value lower limit 2 Can be set. al2l
13 Alarm value 3 Can be set. al-3
14 Alarm value upper limit 3 Can be set. al3h
15 Alarm value lower limit 3 Can be set. al3l
16 Alarm value 4 Can be set. al-4
17 Alarm value upper limit 4 Can be set. al4h
18 Alarm value lower limit 4 Can be set. al4l
19
PV/SP/Internal SP
Can be set. (SP)
*1
---
20
PV/SP/Alarm Value 1
*2
Can be set. (SP)
*1
---
21 Proportional Band (Cooling) Can be set. c-p
22 Integral Time (Cooling) Can be set. c-i
23 Derivative Time (Cooling) Can be set. c-d
000
Setting Item 5
0
pfd5
1
pfd1
