Omron E5 J Series User Manual

E5jJ
E5jJ
Panel Cutout
E5AJ
L
120 min.
92
+0.8
0
92
+0.8
0
92
+0.8
0
Side-by-side Mounting
of N Controllers
L = (96N – 3.5)
+1
0
Side-by-side Mounting
of N Controllers
L = (72N – 3.5)
+1
0
E5BJ
100 min.
L
68
+0.7
0
68
+0.7
0
68
+0.7
0
60 min.
L
45
+0.6
0
E5CJ
Side-by-side
Mounting
of N Controllers
Side-by-side Mounting
of N Controllers
E5EJ
120 min.
L
92
+0.8
0
45
+0.6
0
45
+0.6
0
45
+0.6
0
92
+0.8
0
L = (48N – 2.5)
+1
0
Note: 1. Recommended panel thickness is 1 to 4 mm for
the E5CJ and 1 to 8 mm for the E5AJ, E5BJ, and
E5EJ.
2. Close side-by-side mounting is possible (in a
horizontal
direction).
L = (48N – 2.5)
+1
0
