Omron E5 Z Series User Manual

114
Adjustment Level Section 5-4
Related Parameters
Proportional band (adjustment level): Page 113
This parameter sets the output dead band width for heating/cooling control. A
negative setting sets an overlapping band.
• This parameter sets an area in which the control output is 0 centering
around the set point for a heating/cooling control.
• During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the “deci-
mal point” parameter setting.
Note Set “none” as the unit for Controllers with Analog Inputs.
• This parameter sets the required manipulated variable to remove offset
during stabilization of P or PD control.
Related Parameters
Integral time (adjustment level): Page 113
PID ON/OFF (initial setting level): Page 122
This parameter sets the hysteresis for ensuring stable operation at the ON/
OFF switching point.
• For standard control, use the “hysteresis (heating)” parameter. The “hys-
teresis (cooling)” parameter cannot be used.
See
See
c-db Dead Band
The control system must be set to
heating/cooling control.
Model Setting range Unit Default
Controllers with Thermocouple/Resis-
tance Thermometer Universal-inputs
−199.9 to 999.9 °C or °F
(See note.)
0.0
Controllers with Analog Inputs −19.99 to 99.99 %FS 0.00
Function
Setting
of-r Manual Reset Value
The control must be standard control
and 2-PID control.
The “integral time” parameter must
be set to 0.
Setting range Unit Default
0.0 to 100.0 % 50.0
Function
Setting
See
See
hys Hysteresis (Heating)
The control must be ON/OFF control.
For the “hysteresis (cooling)” param-
eter, the control must be heating/
cooling control.
chys Hysteresis (Cooling)
Function
■
■
