Omron E5 Z Series User Manual

146
Advanced Function Setting Level Section 5-7
• This parameter sets the function to be assigned to control output 1.
Note (1) If c-o is assigned for standard control, a value equivalent to 0% is output.
(2) Can be selected for relay and voltage outputs only.
Related Parameters
Standard or heating/cooling: Page 123, Transfer output type: Page 127 (initial
setting level)
• This parameter sets the function to be assigned to alarm output 1.
Note If c-o is assigned for standard control, a value equivalent to 0% will be
output.
out1 Control Output 1 Assignment
The transfer output type must be set
to OFF when the control output is a
current output.
Setting range Default
none: No function is assigned to control output 1. o
o: Heating control output is output.
c-o: Cooling control output is output. (See note 1.)
alm1: Alarm 1 is output. (See note 2.)
alm2: Alarm 2 is output. (See note 2.)
alm3: Alarm 3 is output. (See note 2.)
Function
Setting
See
See
alm1
Alarm output 1 Assignment
Alarm output 1 must be assigned.
Setting range Default
none: No function is assigned to alarm output 1. alm1
o: Heating control output is output.
c-o: Cooling control output is output. (See note. )
alm1: Alarm 1 is output.
alm2: Alarm 2 is output.
alm3: Alarm 3 is output.
Function
Setting
■
