154
Appendix A
External Dimensions
E54-CT1
E54-CT3
21
15
25
3
40
10.5
5.8 dia.
7.5
2.8
10
30
Two, 3.5 dia.
30
40 × 40
12 dia.
9
2.36 dia.
15
30
Two, M3 holes, depth: 4
