Appendix A
Sensor Input Setting Range, Indication Range, Control Range
Input type Specifications Set value Input temperature range Input indication range
Control-
lers with
Thermo-
couple/
Resis-
tance
Ther-
mome-
ter
Univer-
sal-
inputs
Resistance ther-
mometer
Pt100 0 −200 to 850 (°C)/−300 to
1,500 (°F)
−220 to 870 (°C)/−340 to
1,540 (°F)
1 −199.9 to 500.0 (°C)/−199.9
to 900.0 (°F)
−199.9 to 520.0 (°C)/−199.9
to 940.0 (°F)
2 0.0 to 100.0 (°C)/0.0 to 210.0
(°F)
−20.0 to 120.0 (°C)/−40.0 to
250.0 (°F)
JPt100 3 −199.9 to 500.0 (°C)/−199.9
to 900.0 (°F)
−199.9 to 520.0 (°C)/−199.9
to 940.0 (°F)
4 0.0 to 100.0 (°C)/0.0 to 210.0
(°F)
−20.0 to 120.0 (°C)/−40.0 to
250.0 (°F)
Thermocouple K
5 −200 to 1,300 (°C)/−300 to
2,300 (°F)
−220 to 1,320 (°C)/−340 to
2,340 (°F)
6 −20.0 to 500.0 (°C)/0.0 to
900.0 (°F)
−40.0 to 520.0 (°C)/−40.0 to
940.0 (°F)
J7−100 to 850 (°C)/−100 to
1,500 (°F)
−120 to 870 (°C)/−140 to
1,540 (°F)
8 −20.0 to 400.0 (°C)/0.0 to
750.0 (°F)
−40.0 to 420.0 (°C)/−40.0 to
790.0 (°F)
T9−200 to 400 (°C)/−300 to 700
(°F)
−220 to 420 (°C)/−340 to 740
(°F)
10 −199.9 to 400.0 (°C)/−199.9
to 700.0 (°F)
−1
99.9 to 420.0 (°C)/−199.9
to 740.0 (°F)
E 11 0 to 600 (°C)/0 to 1,100 (°F) −20 to 620 (°C)/−40 to 1,140
(°F)
L12−100 to 850 (°C)/−100 to
1,500 (°F)
−120 to 870 (°C)/−140 to
1,540 (°F)
U13−200 to 400 (°C)/−300 to 700
(°F)
−220 to 420 (°C)/−340 to 740
(°F)
14 −199.9 to 400.0 (°C)/−199.9
to 700.0 (°F)
−199.9 to 420.0 (°C)/−199.9
to 740.0 (°F)
N15−200 to 1,300 (°C)/−300 to
2,300 (°F)
−220 to 1,320 (°C)/−340 to
2,340 (°F)
R 16 0 to 1,700 (°C)/0 to 3,000
(°F)
−2
0 to 1,720 (°C)/−40 to
3,040 (°F)
S 17 0 to 1,700 (°C)/0 to 3,000
(°F)
−20 to 1,720 (°C)/−40 to
3,040 (°F)
B 18 100 to 1,800 (°C)/300 to
3,200 (°F)
0 to 1,820 (°C)/0 to 3,240
(°F)
ES1B Infrared
Temperature
Sensor
10 to 70°C 19 0 to 90 (°C)/0 to 190 (°F) −20 to 130 (°C)/−40 to 270
(°F)
60 to 120°C 20 0 to 120 (°C)/0 to 240 (°F) −20 to 160 (°C)/−40 to 320
(°F)
115 to 165°C 21 0 to 165 (°C)/0 to 320 (°F) −20 to 205 (°C)/−40 to 400
(°F)
140 to 260°C 22 0 to 260 (°C)/0 to 500 (°F) −20 to 300 (°C)/−4
0 to 580
(°F)
Analog input 0 to 50 mV 23 Any of the following ranges,
by scaling:
−1,999 to 9,999
−199.9 to 999.9
−5% to 105% of setting
range. The display shows -
1999 to 9999 (numeric range
with decimal point omitted).
