2 CompoWay/F Communications Procedures
2 - 4
E5@C Digital Temperature Controllers Communications Manual (H175)
The following examples show the end code when a command did not end normally.
Example 1) Illegal Sub-address, No SID, and No Command Text
Command
Response
End code is “16” (sub-address error).
The sub-address error code is used because the sub-address error has a higher error detection
priority than the format error.
Example 2) No Command Text
Command
Response
The end code is “14” (format error).
Example 3) No Node Number Provided
Command
The node number is lacking one character.
Response
There is no response.
2-1-4 Communications Data
Communications
format
Set (monitor)
values
Negative values Decimal point
CompoWay/F 8-digit hexadecimal 2's complement Decimal point is removed and the result is
converted to hexadecimal.
Example conversion: 105.0 1050
H'0000041A
2-1-5 End Code Example
STX 0 A ETX
BCC
Node number Sub-address
A ETX
BCC
16STX 0
Node number
Sub-address
End code
STX 0 0 ETX
BCCSID
0
Node number Sub-address
0ETX
BCC
14STX 0
Node number
Sub-address
End code
STX ETX
BCC
