5 Advanced Operations

5 - 30

E5@C-T Digital Temperature Controllers User’s Manual (H185)

Press the U or D Key to set the value to 8.0.

The default is 8.0 (°C/°F).

• Setting the LBA Band

Press the M Key several times in the Advanced Function Set-

ting Level to display lbab (LBA Band).

Advanced Function Setting

Level

Press the U or D Key to set the value to 3.0.

The default is 3.0 (°C/°F).

8.0

lbal

3.0

lbab

LBA Band

3.0

lbab

Default Chapter6
