Use the following procedure to move to Advanced Function Setting Level.
Step 1: Move to Protect Level.
Step 2: Display icpt (Initial Setting/Communications Protect) and set it to 0.
Step 3: Return to Operation Level.
Step 4: Return to Initial Setting Level.
Step 5: Display amoV (Move to Advanced Function Setting Level) and then enter −169.
Steps 1 to 3 are necessary only the first time. Perform only steps 4 and 5 to move to Advanced
Function Setting Level.
There are five other setting levels: Manual Control Level, Protect Level, Communications Setting
Level, Calibration Level, and Monitor/Setting Item Level.
z Manual Control Level
This level is used to set the MV manually.
• To move from the Operation Level to the Manual Control Level, press the O Key for at least 3
seconds while the Auto/Manual Switch parameter is displayed.
• To use the S Key to move to the Manual Control Level, change the setting of the PF Setting
parameter to a-m.
• To use an event input to move to the Manual Control Level, change the setting of the Event Input
Assignment 1 to 6 parameter to manu.
z Protect Level
This level is used to restrict the operations that can be performed and the parameters that can be
displayed with the front-panel keys. For example, you can prohibit changing the SP and other
parameters in the Operation Level, Program Setting Level, Adjustment Level, and PID Setting Level.
You can move to this level from the Operation Level, Program Setting Level, Adjustment Level, or
PID Setting Level. To move to the Advanced Function Setting Level, you must first cancel the protec-
tion that is set in the Protect Level.
z Communications Setting Level
This level is used to set the communications parameters. You can move to the Communications Set-
ting Level from the Initial Setting Level.
* You can use this level only when control is stopped.
Other Setting Levels
Advanced Function
Setting Level
Power ON
Step 5: Enter −169 for the amoV parameter.
Moves to Advanced Function Setting Level
Enter −169. Default: 0
Operation Level
Step 3: Press
O
and
M
Keys for at least 1 s.
Level changes automatically.
Initial Setting Level
Protect Level
0
icpt
Initial Setting/Communications Protect
Set 0. Default: 1
Step 2: Change the parameter with the
M
Key and change the setting of the icpt parameter to 0.
amov
0
Step 4: Press
O
Key
for at least 3 s.
Step 1:
Press
O
and
M
Keys
simultaneously for at least 3 s.
