3 - 11
3 Part Names and Basic Procedures
E5@C-T Digital Temperature Controllers User’s Manual (H185)
3-3 Part Names, Part Functions, and Setting Levels
3
3-3-3 Setting Levels
z Operation Level
This level is displayed automatically when the power supply is turned ON.
This level is used for the SP and other basic settings and monitoring.
Normally, select this level for operation.
z Program Setting Level
This level is used to set the parameters for the programs (SPs, rates of rise, times, etc.).
z Adjustment Level
This level is used to set the PID constants and to perform tuning, such as autotuning.
z PID Setting Level
This level is used to set the parameters for the PID sets (PID constants, MVs, upper/lower limits,
manual reset values, PID set automatic selection range upper limits, etc.).
z Initial Setting Level
This level is used for the most basic settings.
It is used to set the input type and other parameters.
Use it to set the input type, alarm type, and other basic settings.
* You can use this level only when control is stopped.
z Advanced Function Setting Level
This level is used for advanced settings.
Use it to assign functions to the control outputs and auxiliary outputs.
You will not be able to enter the Advanced Function Setting Level with the default settings.
To enter the Advanced Function Setting Level, first disable Initial Setting/Communications Protection
and then enter the password (−169) at the amov (Move to Advanced Function Setting Level)
parameter in the Initial Setting Level.
* You can use this level only when control is stopped.
Basic Setting Levels
To Next Page
