A - 27
A Appendices
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-6 Parameter Operation Lists
A
A-6-8 Advanced Function Setting Level
A-6-8 Advanced Function Setting Level
Parameters Characters Setting (monitor) value Display Default Unit
Parameter Initialization init OFF, FACT off, fact OFF None
Program End ON Time pend ON: Continue output, 0.0: No output, or 0.1 to 10.0 on, 0.0, or
0.1 to 10.0
0.0 Seconds
Standby Time Unit s-u H-M: Hours and minutes
M-S: Minutes and seconds
h-m
m-s
Hours and
minutes
None
Standby Sequence
Reset
rest Condition A, condition B a, b Condition A None
Auxiliary Output 1
Open in Alarm
sb1n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Auxiliary Output 2
Open in Alarm
sb2n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Auxiliary Output 3
Open in Alarm
sb3n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Auxiliary Output 4
Open in Alarm
sb4n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
HB ON/OFF hbu OFF, ON off, on ON None
Heater Burnout Latch hbl OFF, ON off, on OFF None
Heater Burnout
Hysteresis
hbh 0.1 to 50.0 0.1 A
α alfa 0.00 to 1.00 0.65 None
Integral/Derivative
Time Unit
tidu 1, 0.1 1, 0.1 1 Second
AT Calculated Gain at-g 0.1to 10.0 Standard
Model: 0.8
Position-pro
portional
Model: 1.0
None
AT Hyster e sis at-h Temperature input: 0.1 to 999.9 0.8 (for °C)
1.4 (for °F)
°C or °F
Analog input: 0.01 to 9.99 0.20 %FS
Limit Cycle MV
Amplitude
lcma 5.0 to 50.0 20.0 %
Input Digital Filter inf 0.0 to 999.9 0.0 Second
Moving Average Count mav OFF, 2, 4, 8, 16, or 32
OFF
Times
Automatic Display
Return Time
ret OFF, 1 to 99 off, 1 to 99 OFF Second
Display Brightness brgt 1 to 3 3 None
Alarm 1 Latch a1lt OFF, ON off, on OFF None
Alarm 2 Latch a2lt OFF, ON off, on OFF None
Alarm 3 Latch a3lt OFF, ON off, on OFF None
Alarm 4 Latch a4lt OFF, ON off, on OFF None
Move to Protect Level
Time
prlt 1 to 30 3 Second
Cold Junction
Compensation Method
cjc OFF, ON off, on ON None
Alarm 1 ON Delay a1on 0 to 999 (0: ON delay disabled) 0 Second
Alarm 2 ON Delay a2on 0 to 999 (0: ON delay disabled) 0 Second
Alarm 3 ON Delay a3on 0 to 999 (0: ON delay disabled) 0 Second
Alarm 4 ON Delay a4on 0 to 999 (0: ON delay disabled) 0 Second
Alarm 1 OFF Delay a1of 0 to 999 (0: OFF delay disabled) 0 Second
Alarm 2 OFF Delay a2of 0 to 999 (0: OFF delay disabled) 0 Second
Alarm 3 OFF Delay a3of 0 to 999 (0: OFF delay disabled) 0 Second
Alarm 4 OFF Delay a4of 0 to 999 (0: OFF delay disabled) 0 Second
Manual Output Method mant HOLD or INIT hold, init HOLD None
Manual MV Initial Value mani
−5.0 to 105.0 for standard control
*1
−105.0 to 105.0 for heating/cooling control
*1
0.0 %
RT rt OFF, ON off, on OFF None
