A Appendices
A - 24
E5@C-T Digital Temperature Controllers User’s Manual (H185)
Standard or
Heating/Cooling
s-hc Standard or heating/cooling stnd, h-c Standard None
Control Period
(Heating)
cp 0.1, 0.2, 0.5, or 1 to 99 0.1, 0.2, 0.5, 1
to 99
Relay
output: 20
Voltage
output (for
driving
SSR): 2
Seconds
Control Period
(Cooling)
c-cp 0.1, 0.2, 0.5, or 1 to 99 0.1, 0.2, 0.5, 1
to 99
Relay
output: 20
Voltage
output (for
driving
SSR): 2
Seconds
Direct/Reverse
Operation
orev Reverse operation, direct operation or-r, or-d Reverse
operation
None
Alarm 1Type alt1 0: Alarm function OFF
1: Upper and lower-limit alarm
2: Upper-limit alarm
3: Lower-limit alarm
4: Upper and lower-limit range alarm
5: Upper- and lower-limit alarm with standby
sequence
6: Upper-limit alarm with standby sequence
7: Lower-limit alarm with standby sequence
8: Absolute-value upper-limit alarm
9: Absolute-value lower-limit alarm
10: Absolute-value upper-limit alarm with standby
sequence
11: Absolute-value lower-limit alarm with standby
sequence
12: LBA (Loop Burnout Alarm) (A Standard Model
must be used.)
13: PV change rate alarm
14: SP absolute-value upper-limit alarm
15: SP absolute-value lower-limit alarm
16: MV absolute-value upper-limit alarm
17: MV absolute-value lower-limit alarm
2 None
Alarm 1 Hysteresis alh1 Temperature input: 0.1 to 999.9 for all alarms except
for MV absolute-value upper-limit or MV lower-limit
alarms
0.2 °C or °F
Analog input: 0.01 to 99.99 for all alarms except for
MV absolute-value upper-limit or MV lower-limit
alarms
0.02 %FS
0.01 to 99.99 for MV absolute-value upper-limit or
MV lower-limit alarms
0.50 %
Alarm 2 Type alt2 Same as Alarm 1 Type except that 12 (LBA) cannot
be set.
2 None
Alarm 2 Hysteresis alh2 Temperature input: 0.1 to 999.9 for all alarms except
for MV absolute-value upper-limit or MV lower-limit
alarms
0.2 °C or °F
Analog input: 0.01 to 99.99 for all alarms except for
MV absolute-value upper-limit or MV lower-limit
alarms
0.02 %FS
0.01 to 99.99 for MV absolute-value upper-limit or
MV lower-limit alarms
0.50 %
Alarm 3 Type alt3 Same as Alarm 1 Type except that 12 (LBA) cannot
be set.
2 None
Alarm 3 Hysteresis alh3 Temperature input: 0.1 to 999.9 for all alarms except
for MV absolute-value upper-limit or MV lower-limit
alarms
0.2 °C or °F
Analog input: 0.01 to 99.99 for all alarms except for
MV absolute-value upper-limit or MV lower-limit
alarms
0.02 %FS
0.01 to 99.99 for MV absolute-value upper-limit or
MV lower-limit alarms
0.50 %
Parameters Characters Setting (monitor) value Display Default Unit
