Omron E5CC-T Communications Manual

5 - 19
5 Communications Data for Modbus
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
5-1 Variable Area (Setting Range) List
5
Address
Parameter name Setting (monitor) value Level
4 bytes 2 bytes
1900 3900
Segment 0 Type
*1
H'00000000 (0): Ramp
H'00000001 (1): Soak
H'00000002 (2): Step
Program
setting
1902 3901
Segment 0 SP
*1
SP lower limit to SP upper limit
1904 3902
Segment 0 Slope
*1
H'00000000 to H'0000270F (0 to 9999)
1906 3903
Segment 0 Time
*1
H'00000000 to H'00009959 (0.00 to 99.59) (hours, minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes, seconds)
1908 3904
Segment 1 Type
*1
Same as for segment 0.
to to
1910 3908
Segment 2 Type
*1
to to
1918 390C
Segment 3 Type
*1
to to
1920 3910
Segment 4 Type
*1
to to
1928 3914
Segment 5 Type
*1
to to
1930 3918
Segment 6 Type
*1
to to
1938 391C
Segment 7 Type
*1
to to
1940 3920
Segment 8 Type
*1
to to
1948 3924
Segment 9 Type
*1
to to
1950 3928
Segment 10 Type
*1
to to
1958 392C
Segment 11 Type
*1
to to
1960 3930
Segment 12 Type
*1
to to
1968 3934
Segment 13 Type
*1
to to
1970 3938
Segment 14 Type
*1
to to
1978 393C
Segment 15 Type
*1
to to
1980 3940
Segment 16 Type
*1
to to
1988 3944
Segment 17 Type
*1
to to
*1 These parameters apply to the program that is currently being executed.
In reset status, they apply to the program specified with the Program No. parameter.
