3 Communications Data for CompoWay/F
3 - 6
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
Variable
type
Address Parameter name Setting (monitor) value Level
C1 (81) 0024 Manual MV Standard Models
Standard control:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to 105.0)
Position-proportional Models
Close position-proportional control with the Direct
Setting of Position Proportional MV parameter set
to ON:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Manual
Control
C1 (81) 0026
MV Upper Limit
*1
Standard control or close position-proportional control:
MV lower limit + 0.1 to H'0000041A
(MV lower limit + 0.1 to 105.0)
Heating and cooling control:
H'00000000 to H'0000041A (0.0 to 105.0)
Adjustment
C1 (81) 0027
MV Lower Limit
*1
Standard control or close position-proportional control:
H'FFFFFFCE to MV upper limit − 0.1
(−5.0 to MV upper limit − 0.1)
Heating and cooling control:
H'FFFFFBE6 to H'00000000 (−105.0 to 0.0)
C1 (81) 0028 Move to Protect
Level
H'FFFFF831 to H'0000270F (−1999 to 9999) Protect
C1 (81) 0029 Password to Move
to Protect Level
H'FFFFF831 to H'0000270F (−1999 to 9999)
(Can only be set. The monitor value is always
H'00000000.)
C1 (81) 002A Parameter Mask
Enable
H'00000000 (0): OFF
H'00000001 (1): ON
C1 (81) 002B PF Key Protect H'00000000 (0): OFF
H'00000001 (1): ON
C1 (81) 002C MV Change Rate
Limit
H'00000000 to H'000003E8 (0.0 to 100.0) Adjustment
C1 (81) 002D Position
Proportional Dead
Band
H'00000001 to H'00000064 (0.1 to 10.0)
C1 (81) 002E Open/Close
Hysteresis
H'00000001 to H'000000C8 (0.1 to 20.0)
C1 (81) 0031 Extraction of
Square Root
Low-cut Point
H'00000000 to H'000003E8 (0.0 to 100.0)
C1 (81) 0039 Proportional Band
(Cooling)
*1
H'00000001 to H'0000270F (0.1 to 999.9)
C1 (81) 003A Integral Time
(Cooling)
*1
H'00000000 to H'0000270F
(0 to 9999: Integral/derivative time unit is 1 s.)
(0.0 to 999.9: Integral/derivative time unit is 0.1 s.)
C1 (81) 003B Derivative Time
(Cooling)
*1
H'00000000 to H'0000270F
(0 to 9999: Integral/derivative time unit is 1 s.)
(0.0 to 999.9: Integral/derivative time unit is 0.1 s.)
C1 (81) 003D Work Bit 1 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 003E Work Bit 1 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
*1 The parameter for the currently selected PID set will be accessed. For setup area 1, however, the currently
selected PID set is fixed at PID1.
