3 Communications Data for CompoWay/F
3 - 12
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
Note: The alarm function can also be used in Digital Controllers without auxiliary output terminals. In this case,
confirm alarm occurrences via the status data.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0024 HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
C3 (83) 0025 Heater Burnout
Latch
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0026 Heater Burnout
Hysteresis
H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 0028 α H'00000000 to H'00000064 (0.00 to 1.00)
C3 (83) 002B Input Digital Filter H'00000000 to H'0000270F (0.0 to 999.9)
C3 (83) 002C PV/SP No. 2
Display Selection
H'00000000 (0): Nothing displayed.
H'00000001 (1): PV/SP
H'00000002 (2): PV
H'00000003 (3): SP/SP (character display)/Nothing
displayed
H'00000004 (4): PV/SP/MV (heating) (valve opening
for Position-proportional Models)
H'00000005 (5): PV/SP/MV (cooling)
H'00000006 (6): PV/SP/Program No. or segment No.
H'00000007 (7): PV/SP/Remaining segment time
C3 (83) 002E Automatic Display
Return Time
H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
C3 (83) 002F Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0030 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0031 Alarm 3 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0032 Move to Protect
Level Time
H'00000001 to H'0000001E (1 to 30)
C3 (83) 0033 Integrated Alarm
Assignment
H'00000000 to H'000000FF (0 to 255)
C3 (83) 0034 Cold Junction
Compensation
Method
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0038 Alarm 1 ON Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 0039 Alarm 2 ON Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003A Alarm 3 ON Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003B Alarm 1 OFF Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003C Alarm 2 OFF Delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 003D Alarm 3 OFF Delay H'00000000 to H'000003E7 (0 to 999)
