3 - 13
3 Communications Data for CompoWay/F
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
3-1 Variable Area (Setting Range) List
3
*1 The setting (monitor) range depends on the transfer output type setting. (Refer to Section 5 Parameters in
the E5
@ C-T Digital Temperature Controllers User's Manual (Cat. No. H185).)
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 003E Transfer Output
Typ e
H'00000000 (0): OFF
H'00000001 (1): Present SP
H'00000002 (2): PV
H'00000003 (3): MV (heating) (Disabled for
Position-proportional Models.)
H'00000004 (4): MV (cooling) (for heating/cooling only)
H'00000005 (5): Valve opening
* Only for Position-proportional Models.
Initial
setting
C3 (83) 003F Transfer Output
Upper Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
C3 (83) 0040 Transfer Output
Lower Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
C3 (83) 0041 Control Output 1
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
C3 (83) 0045 RT H'00000000 (0): OFF
H'00000001 (1): ON
Note: Valid only with temperature input.
Advanced
function
setting
C3 (83) 0046 HS Alarm Use H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0047 HS Alarm Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0048 HS Alarm
Hysteresis
H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 0049 LBA Detection
Time
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 004A LBA Level H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
C3 (83) 004B LBA Band H'00000000 to H'0000270F
(0.0 to 999.9 for temperature input)
(0.00 to 99.99 for analog input)
