3 Communications Data for CompoWay/F
3 - 22
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
*1 The set values for the program specified in the Program Selection parameter are accessed for the following
parameters: No. of Segments Used, Segment Selection, PID Set No., Alarm Values 1 to 4, Alarm Upper
Limits 1 to 4, Alarm Lower Limits 1 to 4, Program Repetitions, Program Link Destination No., Time Signal 1
and 2 Set Segments, Time Signal 1 and 2 ON Times, and Time Signal 1 and 2 OFF Times. Check the set
value of the Program Selection parameter before accessing these parameters.
*2 The set values for the program specified in the Program Selection parameter and the section specified in the
Segment Selection parameter are accessed for the following parameters: Segment Type, Segment SP,
Segment Slope, and Segment Time.
Check the set value of the Program Selection and Segment Selection parameters before accessing these
parameters.
Variable
type
Address Parameter name Setting (monitor) value Level
C4 (84) 0000 Program Selection H'00000000 to H'00000007 (0 to 7) Program
setting
C4 (84) 0001 Number of
Segments Used
*1
H'00000001 to H'00000020 (32)
C4 (84) 0002 Segment
Selection
*1
H'00000000 to H'0000001F (31)
C4 (84) 0003
Segment Format
*2
H'00000000 (0): Ramp
H'00000001 (1): Soak
H'00000002 (2): Step
C4 (84) 0004
Segment SP
*2
SP Lower Limit to SP Upper Limit
C4 (84) 0005
Segment Slope
*2
H'00000000 to H'0000270F (0 to 9999)
C4 (84) 0006
Segment Time
*2
H'00000000 to H'00009959 (0.00 to 99.59) (hours,
minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes,
seconds)
C4 (84) 0007
PID Set No.
*1
H'00000000 to H'00000008 (0 to 8), (0): Automatic
selection
C4 (84) 0008
Alarm Value 1
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 0009 Alarm Value Upper
Limit 1
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000A Alarm Value Lower
Limit 1
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000B
Alarm Value 2
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000C Alarm Value Upper
Limit 2
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000D Alarm Value Lower
Limit 2
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000E
Alarm Value 3
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 000F Alarm Value Upper
Limit 3
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 0010 Alarm Value Lower
Limit 3
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 0011
Alarm Value 4
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 0012 Alarm Value Upper
Limit 4
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C4 (84) 0013 Alarm Value Lower
Limit 4
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
