6 Programless Communications
6 - 6
E5@C Digital Temperature Controllers Communications Manual (H175)
MELSEC Q-series, L-series, FX-series, and iQ-R-series PLCs
* Up to 16 E5@C Controllers can be connected to an FX-series PLC.
Keyence KV-series PLCs
Name Model number
Communications ports
Port 1 Port 2
iQ-R Corresponding Serial Communication
Module
RJ71C24
RS-232C
(Cannot be used.)
RS-422/485
Q Corresponding Serial Communication
Module
QJ71C24N
RS-232C
(Cannot be used.)
RS-422/485
QJ71C24N-R4 RS-422/485 RS-422/485
L Corresponding Serial Communication
Module
LJ71C24
RS-232C
(Cannot be used.)
RS-422/485
FX1N/1NC* Corresponding Function
Expansion Board or Special Adapter
FX2NC-485ADP
FX1N-485-BD
RS-485
FX2N/2NC* Corresponding Function
Expansion Board or Special Adapter
FX2NC-485ADP
FX2N-485-BD
Function Expansion Board or Special
Adapter for FX3S/3G/3GC*
FX3U-485ADP-MB
FX3G-485-BD
Function Expansion Board or Special
Adapter for FX3U/3UC*
FX3U-485ADP-MB
FX3U-485-BD
Name Model number
Communications ports
Port 1 Port 2
Serial Communication Unit
KV-L21V
RS-232C
(Cannot be used.)
RS-232C/422A/485

Omron E5CC Specifications

General

Number of Display Digits	4 digits
Number of Control Outputs	1
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage, Analog current
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Display Type	LCD
Size	48 x 48 mm
Mounting Method	Panel mount
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
Protection Rating	IP66
