2 CompoWay/F Communications Procedures
2 - 16
E5@C Digital Temperature Controllers Communications Manual (H175)
Service Request PDU
Service Response PDU
(1) Command Code and Related Information
2-3-8 Operation Command
Communications Writing RUN/STOP Multi-SP
AT Execute/Cancel Write Mode Save RAM Data
Software Reset Move to Setup Area 1 Move to Protect Level
Auto/Manual Switch Parameter Initialization Alarm Latch Cancel
Invert Direct/Reverse
Operation
Program Start SP Mode
Command code Command content Related Information
00
Communications Writing 00: OFF (disabled)
01: ON (enabled)
01
RUN/STOP 00: Run
01: Stop
02
Multi-SP 00: Set point 0
01: Set point 1
02: Set point 2
03: Set point 3
04: Set point 4
05: Set point 5
06: Set point 6
07: Set point 7
03
AT Execute/Cancel 00: AT cancel
01: 100% AT execute
02: 40% AT execute
04
Write Mode 00: Backup
01: RAM write mode
05 Save RAM Data 00
06 Software Reset 00
07 Move to Setup Area 1 00
08 Move to Protect Level 00
09
Auto/Manual Switch 00: Automatic mode
01: Manual mode
0B Parameter Initialization 00
MRC SRC
3005
22
2
2
Com-
mand
code
Related
informa-
tion
MRC SRC
3005
22 4
Response
code
