3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
C1 (81) 003C SP Ramp Fall
Value
H'FFFFFFFF (−1): Same (Same as SP Ramp Set
Value.)
H'00000000(0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjustment
C1 (81) 003D Work Bit 1 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 003E Work Bit 1 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 003F Work Bit 2 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0040 Work Bit 2 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0041 Work Bit 3 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0042 Work Bit 3 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0043 Work Bit 4 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0044 Work Bit 4 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0045 Work Bit 5 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0046 Work Bit 5 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0047 Work Bit 6 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0048 Work Bit 6 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 0049 Work Bit 7 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 004A Work Bit 7 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 004B Work Bit 8 ON
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 004C Work Bit 8 OFF
Delay
H'00000000 to H'0000270F (0 to 9999)
C1 (81) 004D Changed
Parameters Only
H'00000000(0): OFF
H'00000001(1): ON
Protect
Variable
type
Address Parameter name Setting (monitor) value Level

Omron E5CC Specifications

General

Number of Display Digits	4 digits
Number of Control Outputs	1
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage, Analog current
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Display Type	LCD
Size	48 x 48 mm
Mounting Method	Panel mount
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
Protection Rating	IP66
