Com Data
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-8
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 000A Control period (heat) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
Initial set-
ting
C3 000B Control period (cool) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
C3 000C Direct/reverse opera-
tion
H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
C3 000D Alarm 1 type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with standby
sequence
H'00000006 (6): Upper-limit alarm with standby sequence
H'00000007 (7): Lower-limit alarm with standby sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with
standby sequence
H'0000000B (11): Absolute-value lower-limit alarm with
standby sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
C3 000E Alarm 2 type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with standby
sequence
H'00000006 (6): Upper-limit alarm with standby sequence
H'00000007 (7): Lower-limit alarm with standby sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with
standby sequence
H'0000000B (11): Absolute-value lower-limit alarm with
standby sequence
C3 000F Alarm 3 type
(See note 2.)
Same settings as the alarm 2 type
