SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-2
3.1 Variable Area (Setting Range) List
The following table lists the variable areas. Items expressed in hexadecimal in the “Set (monitor) value”
column are the setting range for CompoWay/F communications. The values in parentheses are the
actual setting range. Use the values in parentheses as the setting range for SYSWAY communications.
When there is a section reference for a setting item, refer to that reference for details.
Vari-
able
type
Address Parameter name Setting (monitor) value Level
C0 0000 PV Temperature: Use the specified range for each sen-
sor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS
Operat-
ing
C0 0001 Status (See note 1.) See 3.2 Status for details.
C0 0002 Internal set point
(See note 1.)
SP lower limit to SP upper limit
C0 0003 Heater current 1 value
monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 0004 MV monitor (heating) Standard: H'FFFFFFCE to H'0000041A
(−5.0 to 105.0)
Heating and cooling: H'00000000 to H'0000041A
(0.0 to 105.0)
C0 0005 MV monitor (cooling) H'00000000 to H'0000041A (0.0 to 105.0)
C0 0006 Heater current value 2
monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 0007 Leakage current value 1
monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 0008 Leakage current value 2
monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 0009 Soak time remain moni-
tor
H'00000000 to H'0000270F (0 to 9999)
