Com Data
3.1 Variable Area (Setting Range) List
3-3
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C1 0000 Operation/adjustment
protect
H'00000000 (0): No restrictions in operation and adjust-
ment levels
H'00000001 (1): Move to adjustment level is prohibited.
H'00000002 (2): Display and change of only “PV” and
“PV/SP” parameters is allowed.
H'00000003 (3): Display of only “PV” and “PV/SP” param-
eters is allowed.
Protect
C1 0001 Initial setting/commu-
nications protect
H'00000000 (0): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is dis-
played.)
H'00000001 (1): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is not dis-
played.)
H'00000002 (2): Move to initial setting/communications
setting level is prohibited.
C1 0002 Setup change protec-
tion
H'00000000 (0): OFF (Changing of setup on Controller
display is allowed.)
H'00000001 (1): ON (Changing of setup on Controller dis-
play is prohibited.)
C1 0003 Set point SP lower limit to SP upper limit Operating
C1 0004 Alarm value 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 0005 Upper-limit alarm 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 0006 Lower-limit alarm 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 0007 Alarm value 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 0008 Upper-limit alarm 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 0009 Lower-limit alarm 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 000A Alarm value 3
(See note 2.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 000B Upper-limit alarm
value 3 (See note 2.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 000C Lower-limit alarm
value 3 (See note 2.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
