Omron E5CN - Page 51

Com Data
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-10
Varia
ble
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 0015 Number of multi-SP
uses
H'00000000 (0): No multi-SP
H'00000001 (1): 2SP
H'00000002 (2): 4SP
Advanced
function
setting
C3 0016 Event input assign-
ment 1
H'00000000 (0): None
H'00000001 (1): RUN/STOP (Cannot be set if the “Number
of multi-SP uses” is set to 1 or 2.)
H'00000002 (2): Auto/Manual (Cannot be set if the “Num-
ber of multi-SP uses” is set to 1 or 2.)
H'00000003 (3): Program Start (Cannot be set if the “Num-
ber of multi-SP uses” is set to 1 or 2.) (See
note 6.)
C3 0017 Event input assign-
ment 2
H'00000000 (0): None
H'00000001 (1): RUN/STOP (Cannot be set if the “Number
of multi-SP uses” is set to 2.)
H'00000002 (2): Auto/Manual (Cannot be set if the “Num-
ber of multi-SP uses” is set to 2.)
H'00000003 (3): Program Start (Cannot be set if the “Num-
ber of multi-SP uses” is set to 2.)
(See note 6.)
C3 001A Multi-SP usage H'00000000 (0): OFF
H'00000001 (1): ON
C3 001B SP ramp time unit H'00000000 (0): EU/second
H'00000001 (1): EU/minute
C3 001C SP ramp set value H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
C3 001D Standby sequence
reset
H'00000000 (0): Condition A
H'00000001 (1): Condition B
C3 001E Alarm 1 open in alarm H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
C3 001F Alarm 1 hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C3 0020 Alarm 2 open in alarm H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
C3 0021 Alarm 2 hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C3 0022 Alarm 3 open in alarm
(See note 2.)
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
C3 0023 Alarm 3 hysteresis
(See note 2.)
H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C3 0024 HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
C3 0025 Heater burnout latch H'00000000 (0): OFF
H'00000001 (1): ON
