Omron E5CN - Page 53

Com Data
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-12
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 0032 Protect level move
time
H'00000001 to H'0000001E (1 to 30) Advanced
function
setting
C3 0033 Input error output H'00000000 (0): OFF
H'00000001 (1): ON
C3 0034 Cold junction compen-
sation method
H'00000000 (0): OFF
H'00000001 (1): ON
C3 0035 MB command logic
switching
(See note 7.)
H'00000000 (0): OFF
H'00000001 (1): ON
C3 0036 PV change color H'00000000 (0): ORG
H'00000001 (1): RED
H'00000002 (2): GRN
H'00000003 (3): R-G
H'00000004 (4): G-R
H'00000005 (5): R-G.R
H'00000006 (6): G-O.R
H'00000007 (7): O-G.R
C3 0037 PV stable band H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt multi-input models)
(0.01 to 99.99 for Analog input models)
C3 0038 Alarm 1 ON delay H'00000000 to H'000003E7 (0 to 999)
C3 0039 Alarm 2 ON delay H'00000000 to H'000003E7 (0 to 999)
C3 003A Alarm 3 ON delay
(See note 2.)
H'00000000 to H'000003E7 (0 to 999)
C3 003B Alarm 1 OFF delay H'00000000 to H'000003E7 (0 to 999)
C3 003C Alarm 2 OFF delay H'00000000 to H'000003E7 (0 to 999)
C3 003D Alarm 3 OFF delay
(See note 2.)
H'00000000 to H'000003E7 (0 to 999)
C3 003E Transfer output type H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV monitor (heating)
H'00000005 (5): MV monitor (cooling)
Initial set-
ting
C3 003F Transfer output upper
limit
H'FFFFF831 to H'0000270F (−1999 to 9999) (See note 4.)
C3 0040 Transfer output lower
limit
H'FFFFF831 to H'0000270F (−1999 to 9999) (See note 4.)
C3 0041 Linear current output H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
C3 0042 Input shift type H'00000000 (0): 1-point shift
H'00000001 (1): 2-point shift
Advanced
function
setting
C3 0043 Output status during
error
H'00000000 (0): 0 mA
H'00000001 (1): MV at PV error
