Omron E5CN

SECTION 6 Communications Data for Modbus
6-8
Address Parameter name Setting (monitor) value Level
0D06 Linear current output H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial set-
ting
0D1E SP upper limit The range of values (without decimal point) is as follows:
Temperature: SP lower limit + 1 to Input range upper limit
Analog: SP lower limit + 1 to scaling upper limit
0D20 SP lower limit The range of values (without decimal point) is as follows:
Temperature: Input range lower limit to SP upper limit − 1
Analog: Scaling lower limit to SP upper limit − 1
0D22 Standard or Heating and
cooling
H'00000000 (0): Standard
H'00000001 (1): Heating and cooling
0D24 Direct/reverse operation H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
0D28 PID/OnOff H'00000000 (0): ON/OFF
H'00000001 (1): 2 degrees of freedom PID control
0D2A ST H'00000000 (0): OFF
H'00000001 (1): ON
0D2C Program pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
0E00 Transfer output type H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV monitor (heating)
H'00000005 (5): MV monitor (cooling)
0E0C Control output 1 assign-
ment
When control output 1 is a linear output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
When control output 1 is a pulse output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 5.)
Advanced
function
setting
0E0E Control output 2 assign-
ment
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 5.)
0E14 Event input assignment 1 H'00000000 (0): None
H'00000001 (1): RUN/STOP (Cannot be set if the “Number
of multi-SP uses” is set to 1 or 2.)
