ransfer output specifications are as follows:4 to 20 mA DC,
Permissible load impedance: 600
Ω
max.,
Resolution: Approx. 2,600
Communications
Terminal
numbers 18 to 22
can be used only on Controllers with Communications Units (E53-AK01/02/03). For details on wiring, refer to
Chap-
ter
6, Using the Communications Function
in the
E5AK-T/E5EK-T/E5CK-T User’
s Manual (H88/H89/H90)
.
E5CK Wiring
Power
Supply
Input 100 to 240 V
AC or 24 V
AC/DC to terminal numbers 4 and 5 according to the specification.
5
4
3
2
1
10
9
8
7
6
13 14
11 12
Sensor Input
Connect the input to terminal numbers 6 to 8 as follows according to the input type.
8
7
6
8
7
6
8
7
6
8
7
6
-
+
-
+
-
+
VmA
TC
⋅ PT V I
Thermocouple Platinum resistance
thermometer
Voltage input Current input
5
4
3
2
1
10
9
8
7
6
13 14
11 12
Match
the inputs with the internal jumper settings
for each input type. For thermocouple or platinum resistance thermometer inputs, set the
inputs to a common position (TC/PT) as the temperature input.
Control Output
Terminal
numbers 1
1
and 12 are for control output 1 (OUT1). The five output types and internal equalizing circuits are available according to the
Output
Unit.
5
4
3
2
1
10
9
8
7
6
13 14
11 12
11
12
11
12
L
11
12
L
11
12
L
11
12
L
E53-R4R4 E53-Q4R4
E53-Q4Q4
E53-Q4HR4
E53-Q4HQ4H
E53-V44R4 E53-C4R4
E53-C4DR4
NPN PNP 0 to 10 V 4 to 20mA
+v
+
-
+
-
+
-
+
-
GND
mA
Relay
V
+v
GND
Terminal
numbers 9 and 10 are for control output 2 (OUT2). The three output types and internal equalizing circuits are available according to the
Output
Unit.
10
9
10
9
L
10
9
L
+V
+
-
+
-
GND
E53-Q4Q4 E53-Q4HQ4H
NPN PNP
E53-R4R4 /E53-V44R4
E53-Q4R4 /E53-C4R4
E53-Q4HR4/E53-C4DR4
Relay
+V
GND
To Next Page
