Omron E5GN Datasheet

2 Basic type digital temperature controller E5GN
Lineup
Model Number Structure
Model Number Legend
Controllers
1. Control Output 1
R: Relay output
Q: Voltage output (for driving SSR)
C: Linear current output
2. Auxiliary Outputs
1: One output
2: Two outputs
3. Option
Blank: None
03: RS-485 communications
B: Two event inputs
H: Heater burnout/Heater short/Heater overcurrent detection
(CT1)
4. Input Type
T: Universal thermocouple/platinum resistance thermometer input
L: Analog current/voltage input
5. Power Supply Voltage
Blank: 100 to 240 VAC
D: 24 VAC/VDC
6. Terminal Type
C: Models with screwless clamp terminal block
7. Case Color
Blank: Black
8. Communications Protocol
Blank: None
FLK: CompoWay/F communications
Note: Models cannot be made for all combinations of options that are possible in the model number legend. Confirm model availability in Ordering
Information before ordering.
* Auxiliary outputs are relay outputs that can be used to output alarms or processing results.
* Screw terminal block models available on request.
Screwless clamp
terminal block
Screw terminal block
(on request)
E5GN
Basic Type
Analog input
Temperature input
1 control output
1 control output
1 or 2 auxiliary
outputs
1 or 2 auxiliary
outputs
Analog input
Temperature input
1 control output
1 control output
1 or 2 auxiliary
outputs
1 or 2 auxiliary
outputs
1 2
E5GN-@@@@@-@-@-@
3 4 5 6 7 8
H07E-EN-01+E5GN+Datasheet.fm Seite 2 Mittwoch, 18. November 2009 4:41 16

Omron E5GN Specifications

General

Brand	Omron
Model	E5GN
Category	Temperature Controller
Language	English
